Bolt down round spigot glass fencing spigots are the showoffs of the fencing world making the hugely desirable frameless system possible.

Glass pool fence spigot spacing. Another variance in spigot spacing is when two panel sizes are used in the same run of glass and the two sizes have different spacing based on the recommended table in this instance the lesser of the two spacing sizes should be used. For 1400mm panels the spigot spacing is 250mm from the edge. In the past glass was an expensive option however with the large range of standard size panels that are now available the price has come down. Stainless steel spigots for glass pool fencing we carry 3 shapes of spigots for glass fencing and within these shapes there are different fixing methods.

A glass pool fence is easier to install and more affordable then you might think. How to set the spigot spacing. After configuring where the spigots need to be placed apply masking tape where you intend to drill the. Most spigots are either top mounted using screws through a base plate or core drilled into concrete.

Whether you re a contractor landscaper designer builder or architect aquaview glass pool fences and glass railing systems are sure to be a winning product for your customers. The side with the bolt screw should be visible from the pool side of the fence. If you were using 200mm spigot spacing you will need to mark the glass at 175mm in from the edge of the balustrade panel as the spigots are 50mm wide. Place the spigot onto the glass lining up the outside edge of the balustrade spigot with the line that you marked out in step 2 making sure that the grub screws are facing you.

See how to space spigots for frameless glass pool fencing and glass balustrade. Glass pool fences and glass railings are growing in popularity as a modern design element for new construction and renovation. Using the spigot spacing table mark the center of each spigot on each panel of glass. The sketch below shows the complete mark up.

From edge of the slab risking cracking of the concrete. Follow the guide below to ensure your spigot positioning complies with. Now refer to the spigot spacing details and make markings where to core drill for the spigots. See how to space spigots for frameless glass pool fencing and glass balustrade.

This is how a core drilled spigot should look from inside the fence pool side. If use of a water core drilling machine is not preferred etc. There are some exceptions for instance some face mounted spigots or unique situations require the bolt screw side to face outwards. When other runs of the glass pool fence or balustrade are base mounted to timber with different looking dressing caps.
